2020 Evinrude 115 Specifications

Engine Type: H.O. Inline 3-Cylinder E-TEC G2 D.I.
Bore x Stroke – in (mm): 3.85 x 3.25 (98 x 82.6)
Displacement – cu in (L): 114 (1.9)
Gear Ratio: 2.08:1
Full Throttle RPM Range: 5000-6000 RPM
Starting: Electric
Controls: ICON II
Fuel Induction: E-TEC Direct Injection with stratified low RPM combustion mode
Alternator Output*: Net Amps 14 idle / 22 wot
Trim Method: Power Trim & Tilt
Trim Range: -6° to 15°
Tilt Range: 81°
Lubrication: Multi-Point Targeted Oiling
Oil Tank Capacity – gal (L): 1.9 (7.2)
Recommended Oil: XPS Marine XD100
Recommended Fuel: 87 Octane
Warranty: 5-Year Engine** / 5-Year Corrosion
Mounting Centers – in (mm): Minimum 26 (660)
Color Customization: Over 400 Color Panel Options
Integrated Features: Dual Axis Rigging / iTrim
100% Global Emissions Compliant: EPA 2013 / CARB 3 STAR / European Union

Model Specific Specifications

Installation: Single
Color: Classic White
Shaft Length – in. (mm): 20 (508)
Steering: iSteer DPS
Model No.: K115HWLF
Weight – lb (kg): 415 (188)
Steering Angle: +/- 38°

NOTES:
* Current amp calculated at 13.5 V. ** 2 years of BRP Limited Warranty and 1 year of BRP Extended Service Terms B.E.S.T. † Standard Rotation iSteer DPS model available for single and multiple installation. ‡ Counter Rotation model. Specifications subject to change.  https://iowautotrading.com/
